Last friday failover and Stonith were evil..

Friday, end of the week, almost week-end, almost time to enjoy the warm weather of my hometown and yet…

I. Story

As I said in the introduction, we were friday and ready to go back in France for a weekend. But something went wrong… friday… of course… First we noticed that one of the server was down, hum? I * this server got fenced, but why? I logged to the server and first check the available space, I always do. This how I discovered that / was full. But how in hell? I checked for the biggest file and saw something like:

-rw-r--r--  1 root  root  1.6G Nov 26 15:57 rmtab

What? But rmtab is in /var and it has his own partition. For an unknown reason, at the next reboot the system hasn’t been able to mount every partition and then put everything on /.

How everything collapsed?

The exportfs has been restarted one more time but for this kind of incident, once is once too often:

Pacemaker attemped to restarted the exportfs resource
The resource failed to stop because a function backup_rmtab was called
This took ages and raised the timeout value in the configuration
The node has been fenced
The resource migrated and started on the other node
The function restore_rmtab was called and from the shared storage restored all the content of the rmtab (~1.6G) in /var/lib/nfs/rmtab
The other node went full (/var at least)
Eventually got fenced by the other chaotic node
Over and over again until I disabled Stonith

Hopefully, a quick search on Google and the linux-ha ML led me to the solution.

II. Origin

Say thank you to the exportfs Pacemaker resource agent from the Official Ubuntu 12.04 repository! The rmtab contains the list of all the filesystems currently being mounted by remote machines. When a filesystem is unmounted by a remote machine, the line in the rmtab is just commented out, not deleted. rmtab is used by rpc.mountd. This file needs to be synchronized to ensure a smooth failover and client reconnection. An entry look like this, when the filesystem is mounted:

10.100.20.13:/mnt/exportfs:0x00000001

When the filesystem is unmounted:

10.100.20.13:/mnt/exportfs:0x00000002

Pacemaker backups (by default) the rmtab in the root of the mount point with the following format <mount point>/.rmtab.This could be modified via thermbackup` primitive paramater but always needs to be on the shared export, otherwise the mecanism introduced by the RA doesn’t make sense anymore. Since I already exposed who messed up everything, let’s analyse the content of both functions.

Exportfs backup function from Official Ubuntu 12.04 repository:

backup_rmtab() {
    local rmtab_backup
    if [ ${OCF_RESKEY_rmtab_backup} != "none" ]; then
        rmtab_backup="${OCF_RESKEY_directory}/${OCF_RESKEY_rmtab_backup}"
        grep ":${OCF_RESKEY_directory}:" /var/lib/nfs/rmtab > ${rmtab_backup}
    fi
}

Exportfs restore function from Official Ubuntu 12.04 repository:

restore_rmtab() {
    local rmtab_backup
    if [ ${OCF_RESKEY_rmtab_backup} != "none" ]; then
        rmtab_backup="${OCF_RESKEY_directory}/${OCF_RESKEY_rmtab_backup}"
        if [ -r ${rmtab_backup} ]; then
            cat  ${rmtab_backup} >> /var/lib/nfs/rmtab
            ocf_log debug "Restored `wc -l ${rmtab_backup}` rmtab entries from ${rmtab_backup}."
        else
            ocf_log warn "rmtab backup ${rmtab_backup} not found or not readable."
        fi
    fi
}

As you can the see the problem is in the restore_rmtab function. It copies the content stored on the shared storage (the backup) in /var/lib/nfs/rmtab.

The upstream version of the RA (available on github) prevents the rmtab to grow infinitely by the sort -u command.

restore_rmtab() {
    local rmtab_backup
    if [ ${OCF_RESKEY_rmtab_backup} != "none" ]; then
    rmtab_backup="${OCF_RESKEY_directory}/${OCF_RESKEY_rmtab_backup}"
    if [ -r ${rmtab_backup} ]; then
        local tmpf=`mktemp`
        sort -u ${rmtab_backup} /var/lib/nfs/rmtab > $tmpf &&
        install -o root -m 644 $tmpf /var/lib/nfs/rmtab
        rm -f $tmpf
        ocf_log debug "Restored `wc -l ${rmtab_backup}` rmtab entries from ${rmtab_backup}."
    else
        ocf_log warn "rmtab backup ${rmtab_backup} not found or not readable."
    fi
    fi
}

Thanks to added piece of code, we don’t experience this issue anymore.

III. Problem in action

Simple pacemaker setup:

============
Last updated: Mon Nov 26 21:43:28 2012
Last change: Mon Nov 26 15:37:25 2012 via cibadmin on c2-nfs-01
Stack: openais
Current DC: c2-nfs-01 - partition with quorum
Version: 1.1.6-9971ebba4494012a93c03b40a2c58ec0eb60f50c
2 Nodes configured, 2 expected votes
3 Resources configured.
============

Online: [ c2-nfs-01 c2-nfs-02 ]

 Resource Group: g_exportfs
     p_vip_exportfs (ocf::heartbeat:IPaddr2):   Started c2-nfs-01
     p_fs_exportfs  (ocf::heartbeat:Filesystem):    Started c2-nfs-01
     p_export   (ocf::heartbeat:exportfs):  Started c2-nfs-01

And then one client that mount the NFS share. It was fairly easy to reproduce the problem and to see the grep action and the >> action from the restore_rmtab` function:

$ sudo cat /var/lib/nfs/rmtab
10.100.20.13:/mnt/exportfs:0x00000001
$ sudo crm resource restart g_exportfs
INFO: ordering g_exportfs to stop
waiting for stop to finish . done
INFO: ordering g_exportfs to start
$ sudo cat /var/lib/nfs/rmtab
10.100.20.13:/mnt/exportfs:0x00000001
10.100.20.13:/mnt/exportfs:0x00000001
$ sudo crm resource restart g_exportfs
INFO: ordering g_exportfs to stop
waiting for stop to finish . done
INFO: ordering g_exportfs to start
$ sudo cat /var/lib/nfs/rmtab
10.100.20.13:/mnt/exportfs:0x00000001
10.100.20.13:/mnt/exportfs:0x00000001
10.100.20.13:/mnt/exportfs:0x00000001
10.100.20.13:/mnt/exportfs:0x00000001
$ sudo for i in `seq 40`; do crm resource restart g_exportfs ; done
…
…
…
...
INFO: ordering g_exportfs to stop
waiting for stop to finish . done
INFO: ordering g_exportfs to start
INFO: ordering g_exportfs to stop
waiting for stop to finish .............^CCtrl-C, leaving
INFO: ordering g_exportfs to stop
^CCtrl-C, leaving
$ sudo cat /var/lib/nfs/rmtab | wc -l
33554432
$ sudo du -h /var/lib/nfs/rmtab
1.2G    /var/lib/nfs/rmtab

I had to stop the process because my /var was almost full. At the end, around 30 times restart the resource and got 1.2G file.

Upgrade the exportfs RA:

$ sudo wget https://raw.github.com/ClusterLabs/resource-agents/master/heartbeat/exportfs
--2012-11-26 15:29:34--  https://raw.github.com/ClusterLabs/resource-agents/master/heartbeat/exportfs
Resolving raw.github.com (raw.github.com)... 207.97.227.243
Connecting to raw.github.com (raw.github.com)|207.97.227.243|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 10400 (10K) [text/plain]
Saving to: `exportfs'

100%[============================================================================>] 10,400      --.-K/s   in 0s

2012-11-26 15:29:34 (289 MB/s) - `exportfs' saved [10400/10400]

$ sudo chmod +x exportfs
$ sudo mv exportfs /usr/lib/ocf/resource.d/heartbeat/exportfs
$ sudo crm resource start g_exportfs
$ sudo du -h /var/lib/nfs/rmtab
4.0K    /var/lib/nfs/rmtab

It took 4 seconds to cleanup all the redundant entries in /var/lib/nfs/rmtab.

K Useful links:

It almost looked like Friday 13…
