Start with the RBD support for TGT

A couple a months ago, Dan Mick posted a nice article that introduced the RBD support for iSCSI / TGT. In this article, I will have a look at it.


I. OSD Server side

The following actions must be performed on your OSD nodes.

Add the Ceph extra repositorie since it contains a package version of TGT with the RBD support. And install the package:

$ echo "deb http://ceph.com/packages/ceph-extras/debian $(lsb_release -sc) main" | sudo tee /etc/apt/sources.list.d/ceph-extras.list
$ sudo apt-get update && sudo apt-get install tgt

We can check that tgt has been well compiled with the RBD support:

$ sudo tgtadm --lld iscsi --op show --mode system | grep rbd
    rbd (bsoflags sync:direct)

First provision a new RBD image in Ceph:

$ ceph osd pool create iscsi 128 128
pool 'iscsi' created
$ rbd -p iscsi create iscsi-rbd -s 10240

Register targets on your OSD servers, for this either append the following in /etc/tgt/targets.conf or etc/tgt/conf.d/ceph.conf:

<target iqn.2014-04.rbdstore.example.com:iscsi>
    driver iscsi
    bs-type rbd
    backing-store iscsi/iscsi-rbd  # Format is <iscsi-pool>/<iscsi-rbd-image>
    initiator-address <clients address allowed to map the device>
</target>

Then reload the tgt service:

$ service tgt reload
Updating target framework daemon configuration


II. Client side

It is critical that you disable the RBD caching, using writeback caching while mapping multiple targets on different host could result in data loss or corruption.

It’s important to disable the rbd cache on tgtd host. Set in /etc/ceph/ceph.conf:

[client]
rbd_cache = false

Install open-iscsi on your client machine:

$ sudo apt-get install open-iscsi
$ sudo service open-iscsi restart
[ ok ] Unmounting iscsi-backed filesystems: Unmounting all devices marked _netdev.
[....] Disconnecting iSCSI targets:iscsiadm: No matching sessions found
. ok
[ ok ] Stopping iSCSI initiator service:.
[ ok ] Starting iSCSI initiator service: iscsid.
[....] Setting up iSCSI targets:
iscsiadm: No records found
. ok
[ ok ] Mounting network filesystems:.

Discover the target:

$ iscsiadm -m discovery -t st -p 192.168.0.100 # the IP is the IP of one of your OSD with the TGT
192.168.0.100:3260,1 iqn.2014-04.rbdstore.example.com:iscsi

Map the target:

$ iscsiadm -m node --login
Logging in to [iface: default, target: iqn.2014-04.rbdstore.example.com:iscsi, portal: 192.168.0.100,3260] (multiple)
Login to [iface: default, target: iqn.2014-04.rbdstore.example.com:iscsi, portal: 192.168.0.100,3260] successful.

Check if everything went well:

$ sudo cat /proc/partition
major minor  #blocks  name

   8        0   97650720 sda
   8        1       1792 sda1
   8        2     248064 sda2
   8        3   97400576 sda3
   8      112   10485760 sdh

Check the block size:

$ blockdev --report /dev/sdh
RO    RA   SSZ   BSZ   StartSec            Size   Device
rw   256   512  4096          0     10737418240   /dev/sdh


Moving forward in a next article, I will discuss a multipath implementation to make this setup highly available.
